HEIDENHAIN Announces EnDat 3 Encoder Interface

Thanks,
Quality Digest

منبع: https://www.qualitydigest.com/inside/metrology-news/heidenhain-announces-endat-3-encoder-interface-081623.html

HEIDENHAIN has simplified functional safety aspects of the interface, and EnDat 3 now leverages the industry standard for functional safety: black channel. This makes implementation much easier for OEMs.

Milton Willis, machine tool product specialist at HEIDENHAIN, says, “We’ve listened to feedback from machine tool manufacturers and their end users, as well as OEMs, and have responded by making EnDat 3 faster, more robust, and more fully featured than any competitive product.”

Our PROMISE: Quality Digest only displays static ads that never overlay or cover up content. They never get in your way. They are there for you to read, or not.

The new encoder interface has reduced cabling requirements compared to the previous version, going down to a two- or four-wire setup as opposed to the eight wires previously needed. This reduces cabling requirements and hence cost, which is a significant benefit in the machine tool and robotics sector. For robotics applications, the EnDat 3 also offers bus operation, which allows manufacturers to daisy-chain encoders together to reduce cabling and therefore reduce costs, as well as to simplify design and manufacturing.

EnDat 3 has increased memory and storage capacity and offers the ability to password-protect information that is stored in the encoder. For example, this could be specific code or machine information to which the company or manager might not want to allow full access for operators.

EnDat 3 uses a 200 kHz clock frequency, compared to the 16 kHz of previous versions, and has doubled its supported bandwidth, from 12.5 to a 25 Mb/s. This means that data can be transferred much more quickly.

(HEIDENHAIN: Schaumburg, IL) — HEIDENHAIN Corp. has announced EnDat 3, a new version of its popular absolute position encoder interface. The EnDat 3 interface has all the benefits of previous versions but is even faster and more robust, with simplified functional safety features.

However, someone has to pay for this content. And that’s where advertising comes in. Most people consider ads a nuisance, but they do serve a useful function besides allowing media companies to stay afloat. They keep you aware of new products and services relevant to your industry. All ads in Quality Digest apply directly to products and services that most of our readers need. You won’t see automobile or health supplement ads.

The first commercial version of the interface, EnDat 2.1 was created in 1995. At that time, most encoders used analog or digital incremental interfaces. EnDat 2.1 used an RS-485 output signal, which is more robust and less susceptible to noise.

Published: Wednesday, August 16, 2023 – 12:00

The EnDat 3 interface detects its absolute position, rather than just its position relative to a reference. This is a big advantage when a machine starts up, as it doesn’t require any machine movement to establish its position—which can be extremely time-consuming for large machines. EnDat 3, therefore, enables faster startup, which means more throughput.

The new interface supports an increased number of temperature sensors to monitor temperatures anywhere, from a robotics arm to inside a cabinet. It has also added support for multidimensional encoders, which enables easier installation and simplifies the downstream calculation that’s involved with using multiple reader heads on a single cable.

So please consider turning off your ad blocker for our site.

Quality Digest does not charge readers for its content. We believe that industry news is important for you to do your job, and Quality Digest supports businesses of all types.

Like all the versions of EnDat, the new EnDat 3 is bidirectional, so it can support monitoring and diagnostics. This means it can be used for preventive maintenance, for example, alerting the CNC when a fault is detected.

Metrology

HEIDENHAIN Announces EnDat 3 Encoder Interface

Faster and more robust, with black channel support for functional safety
